SpringBoot使用JasperReports报表引擎的原理与使用实践

5.3 JasperUtil 工具类封装

package com.example.utils;

import ja va.io.ByteArrayOutputStream;
import ja va.io.InputStream;
import ja va.util.List;
import ja va.util.Map;
import ja vax.servlet.http.HttpServletResponse;
import net.sf.jasperreports.engine.*;
import net.sf.jasperreports.engine.data.JRBeanCollectionDataSource;
import net.sf.jasperreports.engine.export.ooxml.JRDocxExporter;
import net.sf.jasperreports.engine.export.ooxml.JRXlsxExporter;
import net.sf.jasperreports.export.*;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;

/**
 * JasperReports 报表工具类.
 * 封装编译、填充、导出的完整流程.
 */
public class JasperUtil {

    private static final Logger log = LoggerFactory.getLogger(JasperUtil.class);

    /**
     * 导出类型枚举.
     */
    public enum DocType {
        PDF, EXCEL, WORD, HTML
    }

    /**
     * 生成报表并写入 HTTP 响应（文件下载）.
     *
     * @param templatePath 模板路径（classpath 下的 .jasper 文件）
     * @param params       报表参数
     * @param dataList     数据集合（对应模板中的 Field）
     * @param fileName     下载文件名
     * @param docType      导出格式
     * @param response     HTTP 响应
     */
    public static  void exportToResponse(
            String templatePath,
            Map params,
            List dataList,
            String fileName,
            DocType docType,
            HttpServletResponse response) {

        try {
            byte[] bytes = generateReport(templatePath, params, dataList, docType);

            // 设置响应头
            String contentType;
            String extension;
            switch (docType) {
                case PDF:
                    contentType = "application/pdf";
                    extension = ".pdf";
                    break;
                case EXCEL:
                    contentType = "application/vnd.openxmlformats-officedocument.spreadsheetml.sheet";
                    extension = ".xlsx";
                    break;
                case WORD:
                    contentType = "application/vnd.openxmlformats-officedocument.wordprocessingml.document";
                    extension = ".docx";
                    break;
                default:
                    contentType = "text/html";
                    extension = ".html";
            }

            response.setContentType(contentType);
            response.setHeader("Content-Disposition",
                "attachment; filename=" + ja va.net.URLEncoder.encode(fileName + extension, "UTF-8"));
            response.setContentLength(bytes.length);
            response.getOutputStream().write(bytes);
            response.getOutputStream().flush();

        } catch (Exception e) {
            log.error("报表导出失败", e);
            throw new RuntimeException("报表导出失败", e);
        }
    }

    /**
     * 生成报表字节数组.
     */
    public static  byte[] generateReport(
            String templatePath,
            Map params,
            List dataList,
            DocType docType) throws Exception {

        // 1. 加载编译好的模板
        InputStream templateStream = JasperUtil.class.getClassLoader()
            .getResourceAsStream(templatePath);
        JasperReport jasperReport = (JasperReport) JRLoader.loadObject(templateStream);

        // 2. 创建数据源
        JRDataSource dataSource;
        if (dataList != null && !dataList.isEmpty()) {
            dataSource = new JRBeanCollectionDataSource(dataList);
        } else {
            dataSource = new JREmptyDataSource();
        }

        // 3. 填充数据 → 生成 JasperPrint
        JasperPrint jasperPrint = JasperFillManager.fillReport(jasperReport, params, dataSource);

        // 4. 导出为目标格式
        ByteArrayOutputStream outputStream = new ByteArrayOutputStream();
        switch (docType) {
            case PDF:
                JasperExportManager.exportReportToPdfStream(jasperPrint, outputStream);
                break;
            case EXCEL:
                exportToExcel(jasperPrint, outputStream);
                break;
            case WORD:
                exportToWord(jasperPrint, outputStream);
                break;
            default:
                JasperExportManager.exportReportToHtmlFile(jasperPrint, outputStream.toString());
        }
        return outputStream.toByteArray();
    }

    private static void exportToExcel(JasperPrint jasperPrint, ByteArrayOutputStream out) throws Exception {
        JRXlsxExporter exporter = new JRXlsxExporter();
        exporter.setExporterInput(new SimpleExporterInput(jasperPrint));
        exporter.setExporterOutput(new SimpleOutputStreamExporterOutput(out));
        SimpleXlsxReportConfiguration config = new SimpleXlsxReportConfiguration();
        config.setOnePagePerSheet(false);
        config.setDetectCellType(true);
        exporter.setConfiguration(config);
        exporter.exportReport();
    }

    private static void exportToWord(JasperPrint jasperPrint, ByteArrayOutputStream out) throws Exception {
        JRDocxExporter exporter = new JRDocxExporter();
        exporter.setExporterInput(new SimpleExporterInput(jasperPrint));
        exporter.setExporterOutput(new SimpleOutputStreamExporterOutput(out));
        exporter.exportReport();
    }
}

5.4 业务代码使用示例

@RestController
public class DeliveryPrintController {

    @Resource
    private DeliveryService deliveryService;

    /**
     * 打印发货单（导出PDF）.
     */
    @GetMapping("/api/delivery/print")
    public void printDeliveryOrder(
            @RequestParam Integer deliveryId,
            HttpServletResponse response) {

        // 1. 查询发货单数据
        DeliveryOrderDto order = deliveryService.getDeliveryOrder(deliveryId);
        List items = deliveryService.getDeliveryItems(deliveryId);

        // 2. 组装报表参数
        Map params = new HashMap<>();
        params.put("companyName", "xxx科技");
        params.put("deliveryCode", order.getDeliveryCode());
        params.put("printDate", DateUtil.formatStandardDate(new Date()));
        params.put("customerName", order.getCustomerName());
        params.put("address", order.getShipToAddress());

        // 3. 导出 PDF
        JasperUtil.exportToResponse(
            "print/delivery_order.jasper",  // classpath 下的模板
            params,
            items,                           // 明细数据
            "发货单_" + order.getDeliveryCode(),
            JasperUtil.DocType.PDF,
            response);
    }

    /**
     * 批量打印（多个发货单合并为一个PDF）.
     */
    @PostMapping("/api/delivery/batch-print")
    public void batchPrint(
            @RequestBody List deliveryIds,
            HttpServletResponse response) {

        List prints = new ArrayList<>();
        for (Integer id : deliveryIds) {
            DeliveryOrderDto order = deliveryService.getDeliveryOrder(id);
            List items = deliveryService.getDeliveryItems(id);

            Map params = new HashMap<>();
            params.put("deliveryCode", order.getDeliveryCode());
            // ... 其他参数

            // 生成每个发货单的 JasperPrint
            InputStream template = getClass().getClassLoader()
                .getResourceAsStream("print/delivery_order.jasper");
            JasperReport report = (JasperReport) JRLoader.loadObject(template);
            JasperPrint print = JasperFillManager.fillReport(report, params,
                new JRBeanCollectionDataSource(items));
            prints.add(print);
        }

        // 合并导出为一个 PDF
        response.setContentType("application/pdf");
        response.setHeader("Content-Disposition", "attachment; filename=batch_delivery.pdf");
        JRPdfExporter exporter = new JRPdfExporter();
        exporter.setExporterInput(SimpleExporterInput.getInstance(prints));
        exporter.setExporterOutput(new SimpleOutputStreamExporterOutput(response.getOutputStream()));
        exporter.exportReport();
    }
}

5.5 模板 DTO 示例

/**
 * 发货单明细DTO（字段名需与JRXML中的Field名称一致）.
 */
@Data
public class DeliveryItemDto {
    private String productCode;    // 对应 $F{productCode}
    private String productName;    // 对应 $F{productName}
    private Integer quantity;      // 对应 $F{quantity}
    private BigDecimal price;      // 对应 $F{price}
}

六、开发流程

6.1 模板设计（使用 Jaspersoft Studio）

1. 下载安装 Jaspersoft Studio（免费，基于 Eclipse）
2. 新建 Jasper Report → 选择模板尺寸（A4/自定义）
3. 拖拽组件到 Band 中：
   - Static Text：固定文本
   - Text Field：动态字段 $F{xxx}
   - Image：图片/Logo
   - Barcode：条码
   - Line/Rectangle：线条/边框
4. 定义 Parameters（外部传入的参数）
5. 定义 Fields（对应数据源的字段）
6. 预览效果 → 保存为 .jrxml
7. 编译为 .jasper → 放到项目 resources/print/ 目录

6.2 项目中的文件组织

src/main/resources/
├── print/
│   ├── delivery_order.jrxml      ← 模板源文件（用于修改）
│   ├── delivery_order.jasper     ← 编译后模板（运行时加载）
│   ├── outbound_order.jasper     ← 出库单模板
│   └── stock_report.jasper       ← 库存报表模板
├── font/
│   └── simsun.ttf                ← 中文字体文件
└── jasperreports.properties       ← JasperReports 配置

七、关键设计总结
